documentation of image (img:) support is missing #219

kirchsth opened this issue Apr 6, 2022 · 0 comments · Fixed by #220
Assignees
Milestone

Comments

@kirchsth
Copy link
Member

kirchsth commented Apr 6, 2022

PR #173 added image support to the sprites (via img: prefix). Related documentation in readme.md is missing.

@startuml
!include https://raw.githubusercontent.com/plantuml-stdlib/C4-PlantUML/master/C4_Container.puml

AddRelTag("plantuml", $textColor="$ARROW_COLOR", $lineColor="$ARROW_COLOR", $sprite="img:http://plantuml.com/logo3.png{scale=0.3}", $legendSprite="img:http://plantuml.com/logo3.png{scale=0.1}", $legendText="console triggered")

Container(containerAlias, "Label", "Technology")
System(systemAlias, "Label", $sprite="img:http://plantuml.com/logo3.png")

Rel(containerAlias, systemAlias, "Label", $tags="plantuml")

SHOW_LEGEND()
@enduml

@kirchsth kirchsth self-assigned this Apr 6, 2022
kirchsth added a commit to kirchsth/C4-PlantUML that referenced this issue Apr 8, 2022
…ith BiRel() calls and unify relation to relationship)
kirchsth added a commit to kirchsth/C4-PlantUML that referenced this issue Apr 8, 2022
…ith BiRel() calls and unify relation to relationship) (2)
kirchsth added a commit to kirchsth/C4-PlantUML that referenced this issue Apr 8, 2022
…ith BiRel() calls and unify relation to relationship)
@kirchsth kirchsth added this to the v2.5.0 milestone Apr 8, 2022
kirchsth added a commit to kirchsth/C4-PlantUML that referenced this issue Apr 10, 2022
kirchsth added a commit that referenced this issue Apr 10, 2022
#219 Update Readme.md (add sprite section, a diagram with BiRel() calls and unify relation to relationship)
@Potherca Potherca moved this to Todo in All Projects Jul 3, 2022
@Potherca Potherca moved this from Todo to Done in All Projects Jul 3, 2022
